LED Video Wall

Get a Price/Quote

LED Video Wall Specification

Control System
Synchronous/Asynchronous Control Systems

Installation Type
Wall-mounted, Hanging, Floor-standing

Pixel Pitch
2.5 mm to 10 mm (custom options available)

Application Areas
Shopping Malls, Events, Stadiums, Airports, Control Rooms

LED Type
SMD (Surface Mounted Device)

Contrast Ratio
4000:1

Features
High Brightness, Seamless Design, Energy Efficient, Easy Maintenance

Voltage
AC 100-240V, 50/60Hz

Panel Size
640 mm x 640 mm / 960 mm x 960 mm (varies with model)

View Angle
140 Horizontal / 140 Vertical

Weight
Approx. 40-60 kg per panel

Power Consumption
Maximum 800 W/m2, Average 280 W/m2

Material
Die-cast Aluminum Cabinet

Usage
Indoor/Outdoor Display

Input Signal
HDMI, DVI, VGA, SDI, AV, USB

Mounting Accessories
Included with panel supply

Frame Frequency
50-60 Hz

Gray Scale
16 bit

Operating Humidity
10% to 90% RH Non-condensing

Cabinet Resolution
256x256 to 384x384 pixels (varies by pixel pitch and panel size)

Operating Temperature
-20C to +50C

Refresh Rate
1920 Hz

IP Rating
IP43 (indoor), IP65 (outdoor)

Brightness
1200 nits (indoor), 4000 nits (outdoor)

Color Temperature
6500K (adjustable)

Screen Lifespan
100,000 hours

LED Video Wall Trade Information

Minimum Order Quantity
10 Square Feet

Payment Terms
Cash in Advance (CID)

Supply Ability
100 Per Month

Delivery Time
7 Days

Main Domestic Market
All India

About LED Video Wall

Pick yours from an unmatchable selection of renowned LED Video Walls, distinguished for their vibrant displays and reliability across India. With indoor brightness up to 1200 nits and outdoor performance at a stunning 4000 nits, these panels deliver clear, vivid content even under challenging conditions. They feature a seamless design, energy efficiency, and easy maintenance, supported by sophisticated control systems and mounting accessories included. Reserve your order today and bring fresh, captivating visuals to events, stadiums, malls, airports, and more with confidence in every pixel.

Versatile Application for Every Environment

The LED Video Wall is expertly crafted for dynamic application methods such as wall-mounting, hanging, and floor-standing setups. Suitable for use in indoor and outdoor environments, these panels are ideal for shopping malls, control rooms, stadiums, airports, and various event venues. Its flexibility in installation, coupled with adjustable pixel pitch and panel size, ensures seamless integration into a wide range of application areas, delivering impressive performance wherever it is deployed.

Domestic Market Reach & Streamlined Transactions

This distinguished LED Video Wall is readily available across the main domestic markets of India with a user-friendly order-processing system. Exchange and payment terms are designed for security and efficiency, accommodating varied client needs. Order completion and delivery times are streamlined, ensuring rapid fulfillment for urgent installations. By prioritizing reliability in supply and customer satisfaction, clients enjoy a worry-free experience from initial inquiry to final delivery of fresh, high-performance video walls.

FAQ's of LED Video Wall:

Q: How is the LED Video Wall installed for different applications?

A: The LED Video Wall can be installed using wall-mounted, hanging, or floor-standing methods depending on site requirements. Each panel comes with mounting accessories to enable flexible and secure installation across various application environments.

Q: What makes this LED Video Wall suitable for outdoor as well as indoor use?

A: With high brightness levels (up to 4000 nits), adjustable color temperature, robust IP ratings (IP65 for outdoor), and broad operating temperature and humidity ranges, this video wall is engineered to perform reliably in both indoor and outdoor settings.

Q: Where can the LED Video Wall be effectively utilized?

A: These video walls are perfect for shopping malls, events, stadiums, airports, control rooms, and numerous other commercial or public spaces, offering brilliant visual impact and uninterrupted performance regardless of the environment.

Q: What is the process for reserving and ordering an LED Video Wall?

A: Simply contact the supplier or authorized trader to discuss your requirements. After confirming specifications and payment terms, your order is processed and reserved for timely delivery and seamless installation.

Q: What benefits do clients receive when choosing this distinguished LED Video Wall?

A: Clients enjoy energy efficiency, high brightness, a seamless design, lifespan up to 100,000 hours, easy maintenance, and versatile signal input support. Additionally, each order includes all necessary mounting accessories and trusted after-sales support.
